| 000护罩与连接件 |
|
 隔板 XQJ-TPC-07 |
|
|
|
序 号
NO. |
型 号 Model |
配套高度
H
Height |
H1 |
H2 |
重量kg
Weight:kg
|
备注
Remarks |
| (H1) |
(H2) |
| 1 |
TPC-07-50 |
50/60 |
35 |
40 |
2.45 |
2.64 |
H1用于梯级桥架
H1 for ladder type cable tray |
| 2 |
TPC-07-50 |
75 |
/ |
65 |
/ |
3.85 |
| 3 |
TPC-07-75 |
100 |
50 |
90 |
13.95 |
4.52 |
| 4 |
TPC-07-75 |
125 |
/ |
115 |
/ |
6.83 |
H2用于托盘式、槽式桥架
H1 for tray type and channel cable tray |
| 5 |
TPC-07-100 |
150 |
75 |
140 |
7.92 |
8.00 |
| 6 |
TPC-07-100 |
200 |
/ |
190 |
/ |
10.83 |
TPC-07 隔板适用于在同一电缆桥架内将动力电缆与控制电缆隔开。
Seperating piece Model TPC-07 is fit for sepersting power form instrument cables insidea tray. |
|
|
| |
|
